Diameter

Seg.Height

Thread

1”(25mm)

10mm

5/8”-11

1-1/8”(28mm)

10mm

5/8”-11

1-1/4”(32mm)

10mm

5/8”-11

1-1/2”(38mm)

10mm

5/8”-11

1-3/4”(45mm)

10mm

5/8”-11

2”(51mm)

10mm

1-1/4”-7UNC

2-1/4”(56mm)

10mm

1-1/4”-7UNC

2-1/2”(63mm)

10mm

1-1/4”-7UNC

3”(76mm)

10mm

1-1/4”-7UNC

3-1/4”(82mm)

10mm

1-1/4”-7UNC

3-1/2”(89mm)

10mm

1-1/4”-7UNC

4”(102mm)

10mm

1-1/4”-7UNC

4-1/4”(108mm)

10mm

1-1/4”-7UNC

4-1/2”(116mm)

10mm

1-1/4”-7UNC

5”(127mm)

10mm

1-1/4”-7UNC

5-1/4”(132mm)

10mm

1-1/4”-7UNC

6”(152mm)

10mm

1-1/4”-7UNC

6-1/4”(159mm)

10mm

1-1/4”-7UNC

6-1/2”(165mm)

10mm

1-1/4”-7UNC

7”(180mm)

10mm

1-1/4”-7UNC

8”(202mm)

10mm

1-1/4”-7UNC

9”(230mm)

10mm

1-1/4”-7UNC

10”(250mm)

10mm

1-1/4”-7UNC

12”(300mm)

10mm

1-1/4”-7UNC

14”(350mm)

10mm

1-1/4”-7UNC
